YUEQING HONGXIANG CONNECTOR MANUFACTURING CO.,LTD.
| Payment Terms | L/C, T/T, Western Union, |
| Supply Ability | 30000 Pieces/Day |
| Delivery Time | 3-30 Day |
| Packaging Details | 38*25*17mm |
| Material | Nickel-plated brass |
| Claw | PA(Nylon),UL94-V2 |
| O-Ring | NBR,Silicone rubber |
| Protection degree | IP68-10 bar |
| Surface Treatment | Electroplating |
| Model NO. | M, PG |
| Brand Name | Hnx waterproof cable gland |
| Model Number | M8-M120 |
| Certification | RoHS, ISO, CE, IP68 |
| Place of Origin | Zhejiang,China |
View Detail Information
Explore similar products
Metric Thread M63 Length Type Underwater Cable Gland Nickel Plated Brass
MG12 Metal Brass Cable Gland Metric Thread Strengthened Type Acid Resistance
M36 Direct Type Metal Brass 20mm Cable Gland With Waterproof IP65 Grade
Multiple - Entry Type Waterproof Cable Gland Connector , Explosion Proof Cable
Product Specification
| Payment Terms | L/C, T/T, Western Union, | Supply Ability | 30000 Pieces/Day |
| Delivery Time | 3-30 Day | Packaging Details | 38*25*17mm |
| Material | Nickel-plated brass | Claw | PA(Nylon),UL94-V2 |
| O-Ring | NBR,Silicone rubber | Protection degree | IP68-10 bar |
| Surface Treatment | Electroplating | Model NO. | M, PG |
| Brand Name | Hnx waterproof cable gland | Model Number | M8-M120 |
| Certification | RoHS, ISO, CE, IP68 | Place of Origin | Zhejiang,China |
| High Light | electrical cable gland ，underwater cable gland | ||
Nickel Plating Cable Gland M Series / Silicone Rubber Metal Cable Gland
USE OF CABLE GLAND
INDUSTRY , CIRCUIT , ELECTRICAL BOX ,
ROBOT INDUSTRY , WIND ENERGY INDUSTRY , LED LAMP ,
MANUFACTURING INDUSTRY , MAINTENANCE INDUSTRY ,
CHARGING PILE INDUSTRY , MOTOR INDUSTRY , TAINENG INDUSTRY AND SO ON .
ITEM
WATERPROOF METRIC TYPE CABLE GLAND
MATERIAL
BRASS,NICKEL PLATED
TEMPERATURE
STATIC : - 40 ºC to 110 ºC , SHORT TIME TO 120 ºC
DYNAMIC : - 20 ºC to 80 ºC , SHORT TIME TO 100 ºC
APPLICANTION
DAY INDOOR,FOR USE WITH ALL TYPES OF SWA EXTRUDED BENDING CABLE
USAGE:
PROVIDES MECHANICAL CABLE RETENTION ELECTRICAL CONTINUITY VIA ARMOURED WIRE TERMINATION
REMARK
WE CAN CUSTOMIZED AS CUSYOMES'REQUIREMENTS.
| Item | Range (mm) | GL Thread Length (mm) | AG Thread O.D. (mm) | H Joint Length (mm) | Spanner size (mm) | Code |
| M8×1 | 2-5 | 5 | 8.0 | 13.5 | 12 | HX-NPM8 |
| M10×1 | 3-6.5 | 6.5 | 10.0 | 17 | 14 | HX-NPM10 |
| M12×1.5 | 3-6.5 | 6.5 | 12.0 | 17 | 14 | HX-NPM12 |
| M14×1.5 | 4-8 | 8 | 14.0 | 18 | 17 | HX-NPM14 |
| M16×1.5 | 4-8 | 8 | 16.0 | 19 | 18 | HX-NPM16 |
| M18×1.5 | 5-10 | 8 | 18.0 | 20 | 20 | HX-NPM18 |
| M20×1.5 | 6-12 | 8 | 20.0 | 21 | 22 | HX-NPM20 |
| M22×1.5 | 10-14 | 8 | 22.0 | 22 | 24 | HX-NPM22 |
| M24×1.5 | 10-14 | 9 | 24.0 | 22 | 24/27 | HX-NPM24 |
| M25×1.5 | 10-14 | 9 | 25.0 | 22 | 24/27 | HX-NPM25-14 |
| M25×1.5 | 11-16 | 9 | 25.0 | 25 | 27 | HX-NPM25-16 |
| M25×1.5 | 13-18 | 9 | 25.0 | 27 | 30/27 | HX-NPM25-18 |
| M27×1.5 | 13-18 | 9 | 27.0 | 27 | 30 | HX-NPM27 |
| M30×2 | 13-18 | 9 | 30.0 | 27 | 30/32 | HX-NPM30 |
| M32×1.5 | 15-22 | 10 | 32.0 | 29 | 35 | HX-NPM32 |
| M33×2 | 15-22 | 10 | 33.0 | 29 | 35/36 | HX-NPM33 |
| M36×1.5 | 18-25 | 10 | 36.0 | 31 | 40 | HX-NPM36 |
| M37×1.5 | 18-25 | 10 | 37.0 | 31 | 40 | HX-NPM37 |
| M40×1.5 | 18-25 | 11 | 40.0 | 31 | 40/45 | HX-NPM40-25 |
| M40×1.5 | 22-30 | 11 | 40.0 | 35 | 45 | HX-NPM40-30 |
| M47×1.5 | 25-33 | 11 | 47.0 | 37 | 50 | HX-NPM47 |
| M50×1.5 | 32-38 | 13 | 50.0 | 37 | 57/55 | HX-NPM50 |
| M60×1.5 | 37-44 | 14 | 60.0 | 38 | 64 | HX-NPM60 |
| M63×1.5 | 37-44 | 14 | 63.0 | 38 | 64/68 | HX-NPM63 |
| M64×2 | 37-44 | 14 | 64.0 | 38 | 64/68 | HX-NPM64 |
| M70×2 | 42-52 | 16 | 70.0 | 44 | 78 | HX-NPM7O |
| M72×2 | 15-22 | 10 | 33.0 | 29 | 35/36 | HX-NPM72 |
| M72×2 | 18-25 | 10 | 36.0 | 31 | 40 | HX-NPM72-58 |
| M75×2 | 18-25 | 10 | 37.0 | 31 | 40 | HX-NPM75 |
| M75×2 | 18-25 | 11 | 40.0 | 31 | 40/45 | HX-NPM75-58 |
| M80×2 | 22-30 | 11 | 40.0 | 35 | 45 | HX- NPM80 |
| M88×2 | 25-33 | 11 | 47.0 | 37 | 50 | HX- NPM88 |
| M100×2 | 32-38 | 13 | 50.0 | 37 | 57/55 | HX-NPM100 |
| M120×2 | 37-44 | 14 | 60.0 | 38 | 64 | HX-NPM120 |
Company profile
Yueqing hongxiang connector manufacturing co., ltd. is a professional manufacturer of various specifications
of wire and cable connectors. The main product is a metal cable waterproof connector
with a protection grade of ip68. it has the characteristics of large clamping cable range,
strong tensile force, waterproof, dustproof, salt resistance, acid and alkali resistance,
alcohol resistance, grease and common solvents, etc. Other products include anti-electromagnetic
cable connector, porous cable waterproof connector, marine stuffing box, reducer head, brass plug cap, etc.
